SKU: RMOUPS-10KVA-01
₹6,00,000.00
High-performance 10kVA rackmount online UPS designed for servers, networking equipment, telecom systems, and data centers.
Only 5 currently available.
| Specification | Value |
|---|---|
| Product Type | Rackmount Online UPS |
| UPS Topology | Online Double Conversion |
| Capacity | 10 kVA |
| Rated Output Power | 10 kW |
| Rack Size | Standard 19-Inch Rack |
| Input Phase | Single Phase / Three Phase (Model Dependent) |
| Output Phase | Single Phase |
| Input Voltage Range | 110V – 300V AC |
| Input Frequency Range | 40Hz – 70Hz |
| Output Voltage | 220V / 230V / 240V AC |
| Output Frequency | 50Hz / 60Hz |
| Output Waveform | Pure Sine Wave |
| Power Factor | 1.0 |
| Efficiency (Online Mode) | Up to 95% |
| Efficiency (ECO Mode) | Up to 98% |
| Transfer Time | 0 Milliseconds |
| Battery Type | External VRLA / SMF Batteries |
| Battery Configuration | 16–20 Batteries (Model Dependent) |
| Battery Charging System | Intelligent Multi-Stage Charging |
| Fast Charging Technology | Supported |
| LCD Display | Yes |
| LED Status Indicators | Yes |
| USB Communication Port | Yes |
| RS232 Communication Port | Yes |
| SNMP Network Management | Optional |
| Emergency Power Off (EPO) | Yes |
| Overload Protection | Yes |
| Short Circuit Protection | Yes |
| Surge Protection | Yes |
| Auto Restart Function | Yes |
| Audible Alarm System | Yes |
| Operating Temperature | 0°C to 40°C |
| Humidity Range | 0–95% Non-Condensing |
| Noise Level | Less than 55 dB |
| Applications | Data Centers, Server Rooms, Telecom Equipment, Storage Systems, Enterprise Networks |
